Tyredog TD-1460-X4 Colour Screen 4x4 Tyre Pressure Monitoring System


SKU: TD-1460A-X4



Recommended Use:

The Tyredog TD-1460-X4 Colour Screen 4x4 Tyre Pressure Monitoring System is recommended to be used for Cars, 4WD's, Light Commercial (Measures up to 80 PSI) It can support up to (4) tyres and can be easily installed within minutes. (D.I.Y) The User-Friendly Graphic Interface (LCD monitor), allows the user to monitor and understand the status of their tyres thus ensuring they are always well maintained. Correct tyre pressure ensures fuel efficiency, reduces tyre wear, while also reducing the risk of hydroplaning due to lack of traction. Necessary check-ups can be costly, requiring much time and attention but with a system designed to regularly monitor your tyres, you can rest easy, knowing your tyres are properly maintained & alerted to potential issues as they arise.

The Design

  • All sensors can be securely locked onto tyre valves for added safety.
  • Learnable sensors are available so in the event of theft or damage, sensors can be quickly and easily replaced.
  • Sensors have unique individual codes to ensure there is no interference from other 433MHz devices, even other TYREDOG™ systems.
  • All TYREDOG™ kits undergo strict field testing to ensure quality.
  • Sensors are treated for anti-corrosion during manufacture and use rubber seals to prevent liquid and fine particles from coming in contact with the circuitry.

    How it works

    The Wireless Sensors are fitted to the wheel's valve stem. To install, simply replace the valve cap with a Wireless Sensor and fit the supplied SecureFit ring to ensure the sensor is securely fastened. This SecureFit ring can also act as a theft deterrent.

    Once the Sensors are fitted and the monitor/receiver is turned on using the supplied DC cable (Cigarette lighter plug), the latest Pressure and Temperature information will be updated on the monitor/receiver. This only takes a couple of minutes or once the wheels rotate.

    The sensors will then transmit any changes in tyre pressure or temperature. If the air Pressure falls or rises above the user preset levels, the unit will sound to alert the driver, alerting him or her to make necessary repairs or adjustments to maintain proper tyre maintenance. A visual indication on the Monitor / Receiver unit can be seen for additional support.

    What's included

    • 1 x Monitor / Receiver (inc 2 x AAA Batteries : Note: Monitor Batteries are for testing purposes only. Unit must be powered using DC Cigarette Lighter power adaptor cable supplied)
    • 4 x Wireless Sensors (inc 4 x CR1632 Batteries)
    • 4 x SecureFit Rings
    • 1 x Suction Cap Mounting Bracket
    • 1 x Cigarette Lighter Power Adaptor Owners Manual

    General Features

    • Small and Compact.
    • Vehicles Battery Voltage is shown in display.
    • Monitors up to 4 tyres.
    • Simply Screw on to the Valve stem and lock in place
    • Audible / Visual Alerts when tyre pressure drops below / raises above user set level
    • Measure Pressure in PSI, KPA, BAR or KgCM
    • Alerts when tyre temperature raises above the user set level. (Adjustments per axle and Spare)
    • Measure Temperature in Celsius or Fahrenheit
    • Provide graphic user interface
    • Monitoring tyre pressure anytime
    • Expands tyre lifespan
    • Saves fuel consumption
    • Improves safety
    • Detects leakage before harm is done
    • Easy to install
    • High accuracy
    • Not affected by bumpy roads
    • Allows user preset value
    • Operates even when the car is stationary
    • Detects both under inflation and over inflation of tyre

    Reliability and Robust

    • All major components are fully exchangeable in case any component is broken
    • Provides signal accessibility by providing peripheral signal integrity technology


    Operating environment (Receiver Unit)

    Operating temperature range

    -20 deg to 80 deg C

    Storage temperature range

    -20 deg to 85 deg C

    Operating humidity


    Power (Receiver Unit)

    OPower Required

    12V DC (MiniDC jack) or Battery DC 3V

    Battery Life:

    Approx. 6 Months

    Battery type

    AAA 1.5V (x2)

    Dimensions Monitor (Receiver Unit)


    60 g


    L 63mm * W 42.5mm* D 20mm

    LCD View size

    L 33.5mm * W 28.2mm

    System (Receiver Unit)

    • System frequency at 433 MHz
    • Sensor pressure range 0-80 psi
    • Sensor pressure sensitivity ± 1.5 psi
    • Sensor temperature sensitivity ±2 deg C
    • Low power consumption in sensor
    • Transmission length: up to 10M (Can vary between vehicle's)

    Emissions (Receiver Unit / Sensors)

    • FCC Comply with part 15,Class B
    • CE
    • C Tick

    Operating environment (Sensors)

    Operating temperature range

    -40 deg to 125 deg C

    Operating humidity



    >1000G from 1.5m height


    10mm 5-200 Hz in X,Y and Z direction

    Power (Sensors)

    Sensor is equipped with battery

    CR1632 (3V)

    Battery Life

    Approx. 1 Year

    Dimensions Sensor (Sensors)


    10g±1 g


    Diameter 18.5mm / Height 20mm

    *Specifications subject to change without notice.

    **Not recommended for monitoring wheels on Trailer / Caravan.
